IP66
BSUMWELL/ OEM
$4.6 - $5.9
| Quantity: | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Engineered for ultimate versatility in towing electrical systems, this multi-functional trailer adapter converts a standard 7-way RV blade vehicle-side socket into both a 6-way round pin and a 4-way flat trailer-side connection. This dual-output capability eliminates the need for multiple single-purpose adapters, allowing seamless towing of utility trailers, boat trailers, livestock haulers, and campers equipped with different wiring configurations. | |||||||||
Engineered for ultimate versatility in towing electrical systems, this multi-functional trailer adapter converts a standard 7-way RV blade vehicle-side socket into both a 6-way round pin and a 4-way flat trailer-side connection. This dual-output capability eliminates the need for multiple single-purpose adapters, allowing seamless towing of utility trailers, boat trailers, livestock haulers, and campers equipped with different wiring configurations.
The integrated 6-way round port features flexible pin arrangement capability (supporting both auxiliary power and electric brake center pin configurations) to match varying trailer wiring standards without requiring permanent rewiring on the primary vehicle.
High-Conductivity Copper Alloy Terminals: Internal terminals and contact pins are fabricated from heavy-gauge copper alloy to ensure low electrical resistance, zero signal drop, and reliable power transfer for high-draw brake circuits, turn signals, and auxiliary lights.
Corrosion-Resistant Housing: Molded from tough, impact-resistant thermoplastic compound engineered to withstand heavy vibration, high tensile stress, and extreme road temperatures.
Dual Weatherproof Dust Covers: Equipped with spring-loaded and tight-fitting rubber dust caps over both the 6-way and 4-way output ports to protect internal contact pins from water, mud, road salt, and dirt when not in active use.
Tool-Free Integration: Fits directly into standard 7-blade RV sockets with a firm push-to-lock action; no wire stripping, splicing, or electrical soldering required.
Ergonomic Finger Grip Wings: Designed with molded side pull tabs for effortless insertion and removal, even when wearing heavy work gloves.
Different trailer manufacturers wire 6-way round plugs with either the center pin dedicated to 12V auxiliary power or electric brakes. This adapter is built to accommodate standard 6-way configurations, ensuring proper signal routing for both lighting functions and brake power depending on your trailer's pinout layout.
No. The unit features a completely plug-and-play design. It plugs directly into your vehicle's existing 7-way RV blade socket, providing instant conversion to 6-way round and 4-way flat connectors without cutting, splicing, or tapping into your vehicle's factory wire harness.
While both ports are active and connected to the same input signals from the 7-way vehicle plug, it is recommended to connect only one trailer at a time to avoid overloading your vehicle's lighting circuits and blowing electrical fuses.
Each output port is fitted with a dedicated weatherproof rubber dust cover. When closed, these caps create a tight seal against rain, road spray, dirt, and road salt, preserving the conductivity of the brass pin connections and preventing corrosion during outdoor exposure.
